ISOLATOR CABLE SET FOR KOMODO OG

ISOLATOR CABLE SET FOR KOMODO OG (NOTE: does not include 12G isolator unless chosen in the dropdown)

This cable set is designed to keep its compact form factor of the OG KOMODO and to be used with a low profile monitor mount (under 4" height mount).  If using a NOGA or other 4" plus cine arm for your monitor, do not choose this setup!.  This set is designed for 90% of compact setups as seen in the pictures on this page.   NOTE: These cable sets are built to order to the sizes specified. DO NOT ORDER unless you have have a very similar setup in the pictures here or have already measured out the lengths you need and they fit within these specifications. Cables include the following: 2x 12G SDI cables, 2x power cables.

From the OG KOMODO SDI port to the MUTINY 12G Isolator

VIDEO 7" SDI Right Angle to Straight
12G Right Angle 12G SDI from camera to Straight 12G SDI to isolator (mounting on AC side) POWER 8”(if the D/P-TAP port is on the  top or AC side of the camera) Safetap V4 protected to 2pin 0B straight

POWER 8" Straight
D/P-TAP or Safetap V4 to 2pin 0B straight
2pin 0B right angle to 2pin 0B straight

From MUTINY 12G Isolator to the monitor or wireless video TX:

VIDEO 12" SDI Straight to Straight or Right Angle
12” 12G SDI straight connector from isolator to straight or right angle connector to the monitor/wireless TX (choose if using a compact monitor mount).

POWER 12” 2pin straight from isolator to these connector options:

2pin straight (SmallHD 703, Cine 5 & 7, Ultra 5, Teradek Bolt, etc) 2pin right angle (SmallHD Cine 5 & 7, Ultra 5, Teradek Bolt, etc)

2.1mm right angle or 2.1mm straight (OSee, Indie 5 & 7, Touch series, Flame Series, Inferno Series and Ninja V series Battery Eliminator, Shogun 7, Shinobi 7, etc),

4pin adjustable for Zacuto (Kamelon Pro)

4pin aviation for Portkeys (EYE III, EYE SDI, BM5 series/HH7/HS7T monitors).

(NOTE: does not include 12G isolator unless chosen in the dropdown)
